Hydraulic injection molding machine from 2024. This BOY XS 161 offers a clamping force of 100 kN and a maximum injection pressure of 2298 bar. It is equipped with a 14 mm screw diameter and a theoretical shot volume of 6.1 cm³. If you are looking for a high-quality injection molding machine, you should consider the BOY XS 161, which we have for sale. Please contact us for more details.

• Control system: Procan ALPHA 4, 15" multi-touch HMI
• Injection pressure: max. 2298 bar (with 14 mm screw)
• Theoretical shot volume: 6.1 cm³
• Tie bar spacing: 160 mm (205 mm diagonal)
• Max. daylight between platens: 250 mm
• Adjustable opening stroke: 150 mm
• Min. mould height: 100 mm (optionally 50 mm)
• Hydraulic system pressure: 300 bar
• Oil tank capacity: 28 liters
• Total installed power: 6.1 kW
• Power supply: 400 V 3~ N, 50/60 Hz, 12.4 A
• Min. machine height: 1380 mm
• Max. machine height: 1692 mm
• Footprint: 0.78 m²
• Safety guard: Fully enclosed clamping area with transparent polycarbonate sliding door and electric interlock
• Peripheral interfaces: Pneumatic and cooling water connections on the non-operator side
Fgjdpfx Asyw I Azslyeb
• Status indicators: 3-stage LED signal tower (Red/Yellow/Green)

Additional equipment (accessories)

• 3-liter gravity material hopper
• Red 16A CEE power plug
• Heavy-duty transport/leveling wooden base
